*K*BANDSAW METAL SWVL HEAD 240V225X180MM
Click on image for larger photo
Product Code: B062V

METAL BANDSAW SWIVEL HEAD 240V 225X180MM
VARIABLE BLADE SPEED 20 TO 90MPM 225 X
180MM @ 90% 2HP MOTOR & SUDS PUMP
Border Image Border Image
Shop Price: $3,799.00
Web Price: $3,799.00  inc tax
Shipping charges may vary and are subject to change based on product dimensions and destination.

Availability: On Order
Quantity:
Weight: 220 KG
Border Image Border Image
FEATURES:
* 225 X 180MM RECTANGULAR CAPACITY
* ELECTRONIC VARIABLE BLADE SPEED, 240V MOTOR
* LARGER CUTTING CAPACITY THAN CONVENTIONAL COLD SAWS
* HEAVY-DUTY GEAR DRIVE SYSTEM
* QUICK-ACTION LOCK/RELEASE VICE
* SWIVEL HEAD MITRE CUT TO 60º RIGHT
* QUICK ACTION LOCK/RELEASE LEVER FOR SWIVEL HEAD
* COOLANT SYSTEM FOR CUTTING EFFICIENCY AND BLADE LIFE
* MATERIAL SUPPORT ROLLER FOR LONG STOCK
* USER FRIENDLY BLADE TENSION SYSTEM
* CONTROL PANEL MOUNTED FOR EASY ACCESS
* ADJUSTABLE LENGTH STOP FOR REPETITION CUTTING
* BALL BEARING BLADE GUIDES ENSURES MINIMAL BLADE CLEARANCE WEAR & INCREASES BLADE LIFE DUE TO LESS FRICTION
* BLADE CLEANING BRUSH INCORPORATED INTO BLADE GUIDE SYSTEM
* ADJUSTABLE HYDRAULIC CYLINDER FOR AUTO FEED
* VIBRATION FREE, LOW NOISE OPERATION ENSURES CLEAN & HIGH PRECISION CUTS
* MACHINE STAND WITH INTEGRATED COOLING FITTED AS STANDARD

MANUFACTURED IN TAIWAN

SPECIFICATIONS:
OPERATION TYPE: SWIVEL HEAD
CUTTING HEAD BEAM TYPE: MANUAL
CUTTING HEAD BEAM RETURN: MANUAL RETURN
CUTTING HEAD DOWN FEED CONTROL: ADJUSTABLE HYDRAULIC
ROUND @ 90º: 225MM
ROUND @ 45º: 150MM
ROUND @ 60º: 100MM
SQUARE @ 90º: 180MM
SQUARE @ 45º: 140MM
SQUARE @ 60º: 100MM
RECTANGLE (WIDTH X HEIGHT) @ 90º: 225 X 180MM
RECTANGLE (WIDTH X HEIGHT) @ 45º: 140 X 140MM
RECTANGLE (WIDTH X HEIGHT) @ 60º: 100 X 100MM
VICE CLAMPING FIXTURE: MANUAL - QUICK ACTION
COOLANT SYSTEM: YES
TABLE WORKING HEIGHT: 950MM
BLADE STEPS / SPEEDS: VARIABLE 20-90 M/MIN
BLADE SIZE (LENGTH X WIDTH X THICKNESS): 2480 X 27 X 0.9MM
MOTOR POWER: 1.5KW / 2HP
VOLTAGE: 240 VOLTS
